Model

CNCPC

Scope of application of pipe (outer diameter)

Φ60-630mm; φ60-800mm; φ150-1000mm; φ200-1250mm;

φ 300-1400mm; φ 600-1600mm;

Pipe length

4 -16 m according to customer requirements

Maximum load

5T or according to pipe diameter

Applicable cutting thickness

Flame 5-50mm, plasma cutting thickness according to plasma power supply model

Number of CNC axes

2/3/4/5/6 axis or extension

X-axis-workpiece rotation

Workpiece rotation drive; amount of rotation: free rotation

Y axis-trolley movement

The torch moves axially along the pipe; the amount of movement: according to the effective cutting length of the equipment

Z-axis-longitudinal lifting of cutting torch

The torch moves longitudinally according to the pipe diameter; The amount of movement: according to the diameter of the workpiece

U-axis-axial deflection of torch

Torch deflection along workpiece axis; deflection angle: flame ± 60 °, plasma ± 45 °

V-axis-torch radial runout

Torch deflection along the radial direction of the workpiece; deflection angle: flame ± 60 °, plasma ± 45 °

W axis-chuck lifting

Chuck longitudinal lifting; movement: according to the workpiece diameter (optional)

Additional Axis-Ovality Adjustment

The cutting torch automatically adjusts the height of the lifting shaft according to the ovality of the workpiece; adjustment amount: 0-20mm
